Copper Conductor PVC Insulation Electrical Cable and Building Wire for House Wiring in 1.5mm to 10mm Sizes

Copper Conductor Electrical Cable

PVC Insulation Building Wire

1.5mm to 10mm House Wiring Cable

인증:

ISO9001, CCC, RoHS, VDE, Is013485

저희와 연락

인용 을 요청 하십시오

제품 상세정보

모델번호:

LK-UL101

도체 재료:

구리

외피 재료:

PVC

단열재:

PVC

재료 모양:

둥근 와이어

응용 프로그램 범위:

PVC 주택 배선 전기 케이블

상표:

링크

격리:

PVC

핵심:

단일 코어

용법:

옥내 배선

재킷:

PVC

운송 패키지:

연타

사양:

1.5mm 2.5mm 4mm 6mm 10mm 단일 코어 코프

등록 상표:

링크

기원:

중국

Hs 코드:

8544492900

공급 능력:

500000미터/일

패키지 크기:

60.00cm * 55.00cm * 50.00cm

패키지 총중량:

30.000kg

유형:

절연

도체 유형:

단단한

어플리케이션:

PVC 주택 배선 전기 케이블

샘플:

US$ 1/미터 1미터(최소 주문) |

맞춤화:

가능 | 맞춤형 요청

배송비:

배송비 및 예상 배송 시간 정보.

초기납부 전액지불

통화:

US $

반품 및 환불:

제품을 수신 한 후 최대 30 일 동안 환불을 신청할 수 있습니다.

강조하다:

Copper Conductor Electrical Cable

PVC Insulation Building Wire

1.5mm to 10mm House Wiring Cable

지불과 운송 용어

Copper Conductor PVC Insulation Electrical Cable and Building Wire for House Wiring in 1.5mm to 10mm Sizes

최고의 가격을 얻으십시오

비디오

내열성 UL1007 PVC 절연 전선 16-28 AWG 주석 도금 구리 케이블, 넓은 온도 범위

최고의 가격을 얻으십시오

비디오

UL1007 케이블 고체 구리 전도기 PVC 단열 넥업 와이어

최고의 가격을 얻으십시오

비디오

유연한 PVC 절연 UL1569 케이블, 300V 정격 105°C 온도 및 연선 구리 도체

최고의 가격을 얻으십시오

저희와 연락

86-0769-81776230

86-18665106395

sales@linkecable.com

지금 연락하세요

제품 설명

Product Overview

Round Wire Copper PVC House Wiring Electrical Cable and Wire Building Wire available in 1.5mm, 2.5mm, 4mm, 6mm, and 10mm sizes for reliable electrical installations.

Product Standards & Features

Product Standards

Manufactured according to GB/T19666-2005, GB/T5023-2008, and JB/T8734-2012 standards for flame-retardant and fire-resistant cables.

Key Cable Features

Voltage rating: Uo/U is 450/750V, 300/500V
Temperature rating: 105°C cables withstand up to 105ºC, other models up to 70ºC

Applications

Suitable for power plants, household appliances, instruments, and telecommunication equipment with rated voltage of 450/750V and below.

Technical Specifications

Voltage (V)	Section (mm²)	Conductors	Max Diameter (mm)	DC Resistance (Ω/km)	Insulation Resistance (MΩ*km)	Current Capacity (A)	Weight (kg/km)
300/500	0.5	1	2.3	36	0.015	13	8.3
300/500	0.75	7	2.6	24.5	0.012	17	10.9
300/500	0.75	1	2.7	24.5	0.014	17	11.8
300/500	1	7	2.8	18.1	0.011	20	13.7
300/500	1	1	3	18.1	0.013	20	14.8
450/750	1.5	1	3.2	12.1	0.011	25	20.0
450/750	1.5	7	3.3	12.1	0.01	25	21.3
450/750	2.5	1	3.9	7.41	0.01	34	31.5
450/750	2.5	7	4	7.41	0.009	34	34.4
450/750	4	1	4.4	4.61	0.0085	44	46.8
450/750	4	7	4.6	4.61	0.0077	44	48.1
450/750	6	1	5	3.08	0.007	58	65.1
450/750	6	7	5.2	3.08	0.0065	58	68.8
450/750	10	7	6.7	1.83	0.0065	79	111
450/750	16	7	7.8	1.15	0.005	111	166
450/750	25	7	9.7	0.727	0.005	146	263
450/750	35	7	10.9	0.524	0.004	180	356
450/750	50	19	12.8	0.387	0.0045	228	487
450/750	70	19	14.6	0.268	0.0035	281	679
450/750	95	19	17.1	0.193	0.0035	344	932
450/750	120	37	18.8	0.153	0.0032	397	1163
450/750	150	37	20.9	0.124	0.0032	456	1424
450/750	185	37	23.3	0.0991	0.0032	519	1789
450/750	240	61	26.6	0.0754	0.0032	592	2335
450/750	300	61	29.6	0.0601	0.003	685	2924
450/750	400	61	33.2	0.047	0.0028	799	3750

Certifications & Compliance

Our products comply with UL1569, 2095, 2103, 2104, 2129, 2463, 2576, 2586, 2587, 2661, 2919, 10012, 10070, 10269, 10483, 20886, and 21664 standards. We are ISO9001 and ISO13485 certified.

CNR Appliance Wiring Material

Extruded PVC Insulated Single, rated 105ºC, 1000V, Class I, Group A, B, or AB, FT1 and/or FT2
Extruded PVC Non-integral Jacketed Cable, rated 105°C, 1000V, Class I, Class or Class I/II, Group A, B, or AB, FT1 and/or FT2

Frequently Asked Questions

1. Are you a manufacturer or trading company?

We are a professional manufacturer. We can control your order from the first beginning to the last. Welcome to visit us. We'll pick you up in Shenzhen.

2. How can I get a sample to test your quality?

The samples are free for you. New clients are expected to pay for the courier cost.

3. What's your Minimum Order Quantity?

Normally 100m. However, the cable is very heavy. You'd better order a suitable quantity to avoid the high freight. Sea transportation is the best option.

4. Can I get a discount?

It depends on your quantity. We can make a discount and afford the freight. Please kindly contact us.

5. Does your company accept OEM production?

Yes, we can print your company name and even customize the quality card to promote your company.
